Product Details:
Payment & Shipping Terms:
|
| Product Name: | Aluminum Extrusion Bar | Alloy: | 6063,6061,6005 |
|---|---|---|---|
| Material: | Aluminum | Suface Treatment: | Mill Finished,Anodized，etc |
| Temper: | T4, T5, T6 ,T66 | Application: | Buildings,commercial,industrial |
| High Light: | extruded aluminum shapes,aluminium profile extrusion |
||
Smoothness Construction Aluminum Profile Customized Powder Spray Coated
Our 4500T grade extrusion machine enable us to produce any section within 400*150mm and φ360.
Your drawings are definitely welcomed.
Price indication: basic aluminium ingot, extrusion cost, surfacing cost and extra.
We also supply fully assembled premium grade window&door systems
| Product Name | Powder Spray Coated Construction Aluminum Profile |
| Grade | 6000 series; 6063 or 6061 |
| Quality Standard | GB5237-2008 |
| Temper | T5 / T6 |
| Color/surface treatment | *Mill finish *Anodized:silver, bronze, golden, etc. *Powder coated:bronze, black, white, etc. *Electrophoresis:silver, bronze, golden, etc. *Sand balsting *PVDF coating *Wood grain painting *Polishing bright |
| Size(Dimension) | Width: up to clients Height: up to clients Length: 5.8 or 6m, up to clients |
| Feature | 1 hight brightness and hardness 2 strong coated adhesion 3 anti-scratch,smoothness 4 high weather resistance, high corrosion resistance,good wear resistance |
| Standard Packaging | PE Film Each PCS, Shrink Film Each Bundle; Or as clients requested |
| MOQ | 1 ton per Item |
Description:
|
Item |
Aluminum Extrusion bar |
|
Material |
Alloy 6063, 6061 or according to customer’ s choice |
|
Temper |
T3, T4, T5, T6 |
|
Surface |
Anodize (clear, satin, bronze, black, golden, silver, other multicolor) , electrophoresis, powder coating, PVDF coating, wood grain painting, etc. |
|
MOQ |
1 ton. Usually 12 tons for a 20 feet container; 24 tons for a 40 feet container. |
|
Profile type |
Industry Aluminum profile used in cars, trains machinery ,trailers ,electronics, medical and other industrial filed . |
|
Machining |
1. milling; 2. Drilling; 3. Bending; 4. Cutting ... |
|
Moulding |
1. Using our moulds, free; 2. Using customer’ s drawing, opening mould fee need to be paid . |
|
Certificate |
ISO14001:2004, ISO9001:2000 |
|
FOB Port |
Shanghai, etc. |
Applications:
Industry Aluminum profile used in cars, trains machinery ,electronics, medical and other industrial filed . In terms of hardware, machinery, electromechanical parts, solar PV products, aluminum frames are adopt as important auxiliary materials. We also have aluminum profiles for radiators, fitness machinery, buildings, lighting instrument, windpipes, oil pipelines, for instance.
Specifications:
1. Primary Technical Data
1) Chemical composition
|
Alloy |
Si |
Fe |
Cu |
Mn |
Mg |
Cr |
Zn |
Ti |
Impurity |
Al |
|
6063 |
0.2-0.6 |
0.35 |
0.1 |
0.1 |
0.45-0.9 |
0.1 |
0.1 |
0.1 |
0.15 |
Rest |
|
6061 |
0.4-0.8 |
0.7 |
0.15-0.4 |
0.15 |
0.8-1.2 |
0.04-0.35 |
0.25 |
0.15 |
0.15 |
Rest |
|
6060 |
0.3-0.6 |
0.1-0.3 |
0.1 |
0.1 |
0.35-0.6 |
- |
0.15 |
0.1 |
0.15 |
Rest |
|
6005 |
0.6-0.9 |
0.35 |
0.1 |
0.1 |
0.40-0.6 |
0.1 |
0.1 |
0.1 |
0.15 |
Rest |
2) Mechanical property
|
Alloy |
Temper |
Tensile strength |
Yield strength |
Elongation |
|
6063 |
T5 |
≥ 160Mpa |
≥ 110Mpa |
≥ 8% |
|
T6 |
≥ 205Mpa |
≥ 180Mpa |
≥ 8% |
|
|
6061 |
T6 |
≥ 265Mpa |
≥ 245Mpa |
≥ 8% |
Competitive Advantage:
1) Engineering design and support.
2) Aluminium profiles deeply processing:cutting,punching,drilling,milling,and fabricating.
3) High Quality system, strictly inspection during production and whole inspection before package.
4) Good performance, product warranty for 15 years.
