Customised V - Slot Aluminium Extrusion Profile EN755 DIN ASTMB221 GB5237-2008 Standard

China Customised V - Slot Aluminium Extrusion Profile EN755 DIN ASTMB221 GB5237-2008 Standard supplier

Large Image :  Customised V - Slot Aluminium Extrusion Profile EN755 DIN ASTMB221 GB5237-2008 Standard

Product Details:

Place of Origin: China
Brand Name: HENTEC,KUNTAI
Certification: CA ,CE ,ISO14001:2004, ISO9001:2000

Payment & Shipping Terms:

Minimum Order Quantity: 1 ton
Packaging Details: Ep paper ,kraft ,pallet
Delivery Time: 20days
Payment Terms: T/T ,L/C
Supply Ability: 100 000ton each month
Contact Now
Detailed Product Description
Product Name: Industrial Aluminium Profile Alloy: 6063 ,6005,6060
Material: Aluminum Suface Treatment: Mill Finished,Anodized ,Electrophoretic Coated,Powder Spray Coated,Drawbench,Steel Polished
Deep Process: Milling, Drilling, Bending,Cutting Temper: T5, T6



OEM Industrial Aluminum Profile , Customized V - Slot Aluminium Extrusion Profile



Product Specification

Commodity:
Customized Anodized Industrial Aluminium Profile Made in China
Shape: Customized, Rectangular,Square,Round.etc
Grade 6000 Series
Species: Window & Door Aluminum Profile/ Decoration Aluminum Profile/ Heat Sink Aluminum Profile/ Glass Wall Aluminum Profile/ Transport Aluminum Profile/ Industrial Aluminum Profile
Color: White/Gray/Gold/Black/Silver/Brown.etc
Alloy: 6063/6005/6061
Temper :  T5 T6
Standard: EN755; DIN; ASTMB221; GB5237-2008 .etc.
Certification: SONCAP/ ISO/ CIQ/ TUV/ ROHS.etc
Surface treatment: Spraying/Wooden-Grain/Oxidation/Electrophoresis.etc
Material: Aluminum Alloy 6063
Design: At buyer's option
Payment term L/C,T/T
Packing standard 1, Each aluminium profile packed in protection plastic film
2, Each bundle profiles wrapped up by compound paper/shrink film/pearl cotton
3, Packed according to customer request
Guarantee term If the shipped products cannot meet required, the total order amount will be refund back without delay, or arrange new replacement cargoes instead.
MOQ 1 ton for each item




Applications:



Our aluminum profile has a wide range of application, like Radiator, Assembly line, Frame system,  Machine Guards, Stairs & Platforms,   Display rack, Automotive, Motor aluminium housing, Bridge system, Vessel, Elevator, etc.









Specifications:



1.Primary Technical Data



1)Chemical composition

Alloy

Si

Fe

Cu

Mn

Mg

Cr

Zn

Ti

Impurity

Al

6063

0.2-0.6

0.35

0.1

0.1

0.45-0.9

0.1

0.1

0.1

0.15

Rest

6061

0.4-0.8

0.7

0.15-0.4

0.15

0.8-1.2

0.04-0.35

0.25

0.15

0.15

Rest

6060

0.3-0.6

0.1-0.3

0.1

0.1

0.35-0.6

-

0.15

0.1

0.15

Rest

6005

0.6-0.9

0.35

0.1

0.1

0.40-0.6

0.1

0.1

0.1

0.15

Rest



2)Mechanical property

  Alloy

Temper

Tensile strength

Yield strength

Elongation

6063

T5

≥ 160Mpa

≥ 110Mpa

≥ 8%

T6

≥ 205Mpa

≥ 180Mpa

≥ 8%

6061

T6

≥ 265Mpa

≥ 245Mpa

≥ 8%





Customised V - Slot Aluminium Extrusion Profile EN755 DIN ASTMB221 GB5237-2008 Standard





Competitive Advantage:



1)Engineering design and support.

2)Aluminum profiles deeply processing:cutting,punching,drilling,milling,and fabricating.

3)High Quality system, strictly inspection during production and whole inspection before package.

4)Good performance, product warranty for 15 years.



      Customised V - Slot Aluminium Extrusion Profile EN755 DIN ASTMB221 GB5237-2008 Standard
