Product Details:
Payment & Shipping Terms:
|
| Material: | Aluminum | Surface: | Powder Painting |
|---|---|---|---|
| Logo: | Silk Screen | Water Proof: | Water Proof |
| Usage: | Out Door / In Door | Warranty: | 15years |
| High Light: | extruded aluminum enclosure boxes,extruded aluminum housing |
||
Milling Aluminum Electrical Shell / CNC Machining Electrical Cover / Shell
Hentec Industrial Co.,Ltd is among the leading aluminium extrusion companies in China and a pioneer in the production and innovation of Aluminium extruded products. The foundation of the company was laid in the year 2007 and today with more than 10 years of industrial experience Hentec has created a niche for itself in the field of manufacturing and supply of aluminium extrusions.
1. Reliable quality (ISO9001:2008 certified).
2. Competitive prices with short lead-time for both tooling and parts, because we do everything in-house.
3. Effective and strong technical support and excellent sales services.
4. Sufficient production capacity (only 65% occupied).
5. Efficient communication (48-hour quote lead time).
6. Compliant with RoHS Test.
1. Material: Aluminium alloy 6063,,6061,6061,6082,6060,6005 or according to customer's request
2. Temper: T5, T6
3. Quality standard: GB5237-2008
4. Surface treatment: Mill finish, anodized, powder coated, electrophoresis, sand balsting etc. PVDF coating, wood grain painting, matted, polishing bright
5. Color avalilable: Silver, Bronze, champagne ,Matte,Natural for andodizing, Ral for powder coating
6. Packing details: Protected film inside and shrinking film outside
7. Samples time: two weeks after receive the mold fee
8. Delivery: 20 days after deposit
9. Production Capacity: 5000MT/Month
10. MOQ: 1 TONS
12. Payment terms: 30% deposit the balance pay against B/L copy within 7 days
13. Port: QINGDAO PORT
14. 22 press extruder
15. OEM & ODM service.
Certificate
ISO 9001/ ISO 14001,SGS
Warranty
1. GB5237-2008 equal to EN12020-1.2(2001);
2. GB6892-2006 equal to DIN 1725
3. Within 15 years without color changing, all life without surface peeling off;
Moulding
we open the new die within 10days
Applications:
Industry Aluminum profile used in cars, trains machinery ,electronics, medical and other industrial filed . In terms of hardware, machinery, electromechanical parts, solar PV products, aluminum frames are adopt as important auxiliary materials. We also have aluminum profiles for radiators, fitness machinery, buildings, lighting instrument, windpipes, oil pipelines, for instance.
Specifications:
1. Primary Technical Data
1)Chemical composition
| Alloy | Si | Fe | Cu | Mn | Mg | Cr | Zn | Ti | Impurity | Al |
| 6063 | 0.2-0.6 | 0.35 | 0.1 | 0.1 | 0.45-0.9 | 0.1 | 0.1 | 0.1 | 0.15 | Rest |
| 6061 | 0.4-0.8 | 0.7 | 0.15-0.4 | 0.15 | 0.8-1.2 | 0.04-0.35 | 0.25 | 0.15 | 0.15 | Rest |
| 6060 | 0.3-0.6 | 0.1-0.3 | 0.1 | 0.1 | 0.35-0.6 | - | 0.15 | 0.1 | 0.15 | Rest |
| 6005 | 0.6-0.9 | 0.35 | 0.1 | 0.1 | 0.40-0.6 | 0.1 | 0.1 | 0.1 | 0.15 | Rest |
2) Mechanical property
| Alloy | Temper | Tensile strength | Yield strength | Elongation |
| 6063 | T5 | ≥ 160Mpa | ≥ 110Mpa | ≥ 8% |
| T6 | ≥ 205Mpa | ≥ 180Mpa | ≥ 8% | |
| 6061 | T6 | ≥ 265Mpa | ≥ 245Mpa | ≥ 8% |
2. Specifications:
Excellent material for smooth and subtle edges.
Elegant appearance.
Surface treatment: colorful anodized or electrostatic powder coated.
Suitable for constructions and other industrial purposes.
Customized surface finishes are welcome.
Competitive Advantage:
1) Engineering design and support.
2) Aluminum profiles deeply processing:cutting,punching,drilling,milling,and fabricating.
3) High Quality system, strictly inspection during production and whole inspection before package.
4) Good performance, product warranty for 15 years.
