6005 Anodized Radiator Aluminum Heat Sink Enclosure

6005 Anodized Radiator Aluminum Heat Sink Enclosure
6005 Anodized Radiator Aluminum Heat Sink Enclosure 6005 Anodized Radiator Aluminum Heat Sink Enclosure

Large Image :  6005 Anodized Radiator Aluminum Heat Sink Enclosure

Product Details:

Place of Origin: China
Brand Name: HENTEC
Certification: CA ,CE

Payment & Shipping Terms:

Minimum Order Quantity: 1 ton
Packaging Details: Ep paper ,kraft ,pallet
Delivery Time: 20days
Payment Terms: T/T ,L/C
Supply Ability: 100 000ton each month
Detailed Product Description
Product Name: Aluminum Heatsink Extrusion Profiles Alloy: 6063,6061,6005
Material: Aluminum Suface Treatment: Mill Finished,Anodized ,Electrophoretic Coated,Powder Spray Coated
Deep Process: Milling, Drilling, Bending,Cutting Temper: T4, T5, T6 ,T66
High Light:

heatsink extrusion profiles

,

extruded heat sink profiles



Anodized Radiator Aluminium Heatsink Extrusion , Aluminum Heat Sink Enclosure



Our company funded in 2003, it is a professional manufacturer of R & D, production and sales of various electronic radiators.

Our  company located in Jiangsu Province, near Shanghai Port , with a very superior geographical position. Our company has more than 600 employees, 50 R & D and structural design personnel, and 500 000 square meter standardized plant.

Our company mainly produces the following series of products: profile radiator, insert radiator, spade radiator, high-density tooth radiator, case integrated radiator, water-cooling radiator, resistance radiator, interdigital radiator and various aluminum alloy profiles for case and cabinet, aluminum bar for power electronics, bridge profile, bus duct and other industrial aluminum alloy profiles.





Quality Control: We operate the most strict quality system,the detection is from the material,production process to final product,and ensure the product quality.

Process: Die design--Die making--Smelting and alloying--Quality control--Extruding--Cutting--Heat treatment--Surface treatment--Welding--Packing

Packing: Packed with plastic film, then wrap by craft paper or EPE film.



Technology Supports

1. Engineering Design.

2. Quality Standard: China GB, according to the Drawing and the Customer's Details.


Specifications:
1. Primary Technical Data
1) Chemical composition

Alloy

Si

Fe

Cu

Mn

Mg

Cr

Zn

Ti

Impurity

Al

6063

0.2-0.6

0.35

0.1

0.1

0.45-0.9

0.1

0.1

0.1

0.15

Rest

6061

0.4-0.8

0.7

0.15-0.4

0.15

0.8-1.2

0.04-0.35

0.25

0.15

0.15

Rest

6060

0.3-0.6

0.1-0.3

0.1

0.1

0.35-0.6

-

0.15

0.1

0.15

Rest

6005

0.6-0.9

0.35

0.1

0.1

0.40-0.6

0.1

0.1

0.1

0.15

Rest


2) Mechanical property

  Alloy

Temper

Tensile strength

Yield strength

Elongation

6063

T5

≥ 160Mpa

≥ 110Mpa

≥ 8%

T6

≥ 205Mpa

≥ 180Mpa

≥ 8%

6061

T6

≥ 265Mpa

≥ 245Mpa

≥ 8%


6060 6061 extruded aluminum heatsink for Led Light ROHS / SGS

Our Advantages:


1. 17+ years experience in providing ONE-STOP customized aluminium extrusion and machining solution; 11+ years of exporting to 40+ countries;
2. 100% new material
3. Competitive prices with short lead-time for both tooling and parts, because we do everything in-house
4. Effective and strong technical support (30+ engineers) and excellent sales services .
5. Sufficient production capacity (22 extrusion lines; 3+ CNC machines).
6. Efficient communication (48-hour quote lead time).


     6005 Anodized Radiator Aluminum Heat Sink Enclosure 1
