High Power Led Light Mill Finished Aluminum Heatsink Extrusion Profiles 6061

China Hentec Industry Co.,Ltd certification
China Hentec Industry Co.,Ltd certification
Thanks a lot for your support for more than 8 years ,we are really appreciate for the good quality of the products and the quality service .

—— James Scott

We have received the goods , they look perfect ,thanks for the help of Team Hentc .

—— Ane Unamuno

Le succès de ce nouveau projet dépend du support de l’équipe HENTEC en termes de technologie de traitement. Merci à HENTEC de nous aider à contrôler les coûts de manière efficace et à répondre à nos exigences en termes de haute qualité. Nous nous réjouissons de notre future collaboration!

—— Yann Pauwels

I'm Online Chat Now

High Power Led Light Mill Finished Aluminum Heatsink Extrusion Profiles 6061

High Power Led Light Mill Finished Aluminum Heatsink Extrusion Profiles 6061
High Power Led Light Mill Finished Aluminum Heatsink Extrusion Profiles 6061
video play

Large Image :  High Power Led Light Mill Finished Aluminum Heatsink Extrusion Profiles 6061

Product Details:
Place of Origin: China
Certification: CA ,CE
Payment & Shipping Terms:
Minimum Order Quantity: 1 ton
Packaging Details: Ep paper ,kraft ,pallet
Delivery Time: 20days
Payment Terms: T/T ,L/C
Supply Ability: 100 000ton each month
Detailed Product Description
Product Name: Aluminum Heatsink Extrusion Profiles Alloy: 6063,6061
Material: Aluminium Suface Treatment: Anodized ,Electrophoretic Coated,Powder Spray Coated
Deep Process: Milling, Drilling, Bending,Cutting Temper: T5, T6
High Light:

aluminum heatsink extrusion profiles 6061

,

mill finished aluminum heatsink extrusion profiles

,

heatsink extrusion profiles mill finished

High Power Led Light Heatsink Extrusion Profiles , Aluminium Heat Sink



Our company MetalPlus is engaged in the research, development, production and sales of aluminum heat sink , electrical shell ,fan blade profile ,architectural doors and windows, curtain wall aluminum profiles and various industrial profiles.

 Our Advantages:
1. 17+ years experience in providing ONE-STOP customized aluminium extrusion and machining solution; 11+ years of exporting to 40+ countries;
2. ISO: 9001:2008,RoHS, SGS, Reach, D&B
4. 100% new material
5. Competitive prices with short lead-time for both tooling and parts, because we do everything in-house
6. Effective and strong technical support (30+ engineers) and excellent sales services .
7. Sufficient production capacity (22 extrusion lines; 3+ CNC machines).
8. Efficient communication (48-hour quote lead time).

Description :

1. Material: Aluminium alloy 6063, 6061.
2. Temper: T5, T6.
3. Quality standard: DIN, AAMA, CHINA GB.
4. Surface treatment: Mill finish, anodized, powder coated, electrophoresis, sand balsting etc.
5. Color avalilable: Silver, Any is available.
6. Packing details: Shrinking film;Plastic & kraft paper;Wooden pallet
Carton packing;By customer's requirements.
7. Samples time: One or two weeks.
8. Delivery: 20-25 Days for Mass Production.
9. Production Capacity: 6000MT/Month
10. MOQ: 1 TONS
12. Payment terms: T/T
13. Port: Shanghai;As per requested.


Applications:
Aluminum heat sink is widely used on Machines , cars , lighter ...

Specifications:
1. Primary Technical Data
1)Chemical composition

Alloy

Si

Fe

Cu

Mn

Mg

Cr

Zn

Ti

Impurity

Al

6063

0.2-0.6

0.35

0.1

0.1

0.45-0.9

0.1

0.1

0.1

0.15

Rest

6061

0.4-0.8

0.7

0.15-0.4

0.15

0.8-1.2

0.04-0.35

0.25

0.15

0.15

Rest

6060

0.3-0.6

0.1-0.3

0.1

0.1

0.35-0.6

-

0.15

0.1

0.15

Rest

6005

0.6-0.9

0.35

0.1

0.1

0.40-0.6

0.1

0.1

0.1

0.15

Rest


2) Mechanical property

  Alloy

Temper

Tensile strength

Yield strength

Elongation

6063

T5

≥ 160Mpa

≥ 110Mpa

≥ 8%

T6

≥ 205Mpa

≥ 180Mpa

≥ 8%

6061

T6

≥ 265Mpa

≥ 245Mpa

≥ 8%


Competitive Advantage:
We can offer professional Manufacturing and exporting service, OEM/ODM for Metal & Plastic parts in China. All the parts manufactured by CNC Lathe & Milling Machine Center.
