Pump Cylinder Shell Aluminum Customized Precision Investment Die Casting

Large Image : Pump Cylinder Shell Aluminum Customized Precision Investment Die Casting

Product Details:

Certification:	ISO 9001:2000
Document:	Product Brochure PDF

Payment & Shipping Terms:

Minimum Order Quantity:	100
Price:	1.99

Contact Now

Detailed Product Description

Material:	Aluminum Alloy	Surface Treatment:	Anodizing
Tolerance Grade:	7	Casting Surface Quality:	12.5
Casting Dimension Tolerance:	CT7-CT8	Casting Surface Roughness:	Ra 12.5um
Casting Weight Range:	0.1-100kg	Max Linear Size:	1200mm
Max Diameter Size:	600mm	Machining Precision:	Positioning Accuracy 0.008mm, Rep. Position. Accuracy 0.006mm
Machining Surface Roughness:	Ra0.8~6.3um	Max Travel Of Spindle:	1800mmx850mmx700mm
Max Turning Diameter:	1000mm	Casting Process Type:	High Pressure Die Casting (HPDC), Vertical Low Pressure Die Casting (LPDC), Precision Sand Casting, Lost Foam Casting, Investment Casting
Production Capacity:	10000 Pieces/Year
Highlight:	customized aluminum die casting parts , precision investment die casting shell , pump cylinder aluminum die casting

Pump Cylinder Shell Aluminum Customized Precision Investment Die Casting

Metalplus specializes in aluminum industrial profile design and manufacturing with a production base of more than 100,000 square meters and annual capacity exceeding 100,000 tons.

Product Portfolio

Aluminum Profile	Aluminum Fan Blade Profiles
Aluminum Profile System Aluminum Extrusion Enclosure LED Aluminum Extrusion Profiles Aluminum Frame Customized Aluminum Profile Aluminum Heat Sink Electric Motor Housing Aluminum profile Construction Aluminum Profile Aluminum Extrusion Tube	Die Casting Die Casting Led Housing Stainless Steel Casting Aluminum Casting ACP \| Aluminum Composite Panel

Product Description

Aluminum is the most frequently used material for aluminum castings to produce lightweight parts. The basic principle of low pressure casting involves filling aluminum molds with liquid aluminum alloy under low working pressure (0.06-0.15MPa) to obtain high-quality castings through controlled solidification.

Precision die casting parts are widely used in hardware components, automotive motor parts, machinery parts, medical equipment, and various industrial applications.

Technical Specifications

Material	Aluminum Alloy, Carbon Steel, Alloy Steel, Stainless Steel
Process	Drawings → Mould Making → Die Casting → Rough Machining → CNC Machining → Surface Treatment → Product Checking → Packing → Delivery
Casting Dimension Tolerance	CT7-CT8
Casting Surface Roughness	Ra 12.5um
Casting Weight Range	0.1-100kg
Casting Size	Max linear size: 1200mm, Max diameter size: 600mm
Machining Precision	Positioning accuracy 0.008mm, Repeat positioning accuracy 0.006mm
Machining Surface Roughness	Ra0.8~6.3um
Max Travel Of Spindle	1800mm x 850mm x 700mm
Max Turning Diameter	1000mm
Material Standard	GB, ASTM, AISI, DIN, BS, JIS, NF, AS, AAR
Surface Treatment	Electroplating, Chrome Plating, Zinc Plating, Nickel plating, Electrophoresis, Anodization, Polishing, Powder coating, Sandblasting, Passivation, Spray painting, etc.
Casting Process Type	High Pressure Die Casting (HPDC), Vertical Low Pressure Die Casting (LPDC), Precision Sand Casting, Lost Foam Casting, Investment Casting, Metal Casting
Service Available	OEM & ODM
Quality Control	0 defects, 100% inspection before packing
Application	Train & railway, automobile & truck, construction machinery, forklift, agricultural machinery, shipbuilding, petroleum machinery, construction, valve and pumps, electric machine, hardware, power equipment
MOQ	1 TON
Payment Terms	T/T, L/C at sight
Port	Shanghai Port

Company Advantages

We export the majority of our customized products to the United States and Europe, building long-term relationships with regular customers. Our extensive experience enables us to easily satisfy diverse customer requirements.

Over 17 years of manufacturing experience in Aluminum Extrusion
Strong design capabilities and fast processing speeds for extrusion, CNC machining, milling, and turning
Complete metal processing capabilities including laser cutting, CNC bending, welding, and stamping
Comprehensive quality control throughout the manufacturing process for long-term stability and excellent quality

Technical Support Services

Custom design services for extruded profiles including CAD drawings and 3D models
Professional R&D team for design analysis and optimization to reduce costs and improve performance
One-stop service model covering product design, mold customization, aluminum bar melting, extrusion profiling, precision machining, and surface treatment

Manufacturing Capabilities

Extrusion

Equipped with 44 aluminum extrusion lines capable of producing commercial and industrial aluminum profiles with maximum outer diameter of 350mm. Our largest 6800-ton extruder handles complex industrial profiles up to 600mm diameter.

Anodizing

Six anodizing production lines create uniform oxidation films for improved corrosion resistance, hardness, and wear resistance. Available in silver, black, gold, champagne, and imitation steel colors with custom options available.

Painting

Four powder spraying lines using high-quality Gema Switzerland spray nozzles with environmentally friendly, durable paints featuring strong adhesive force and color retention.

CNC Machining

Advanced machining equipment operated by experienced technicians ensures precision and quality:

12 PRATIC machining centers for milling, drilling, and tapping profiles up to 6 meters
Fully automatic Wegoma cutting machines for precise, efficient cutting
30 punching machines (50-100 ton capacity) for thick profiles over 5mm
10 stretch bending machines for precise arc and angle bending
10 milling machines for planes, bevels, and grooves

Packing & Shipping

Finished products are manually packaged and prepared for delivery. Strict warehouse management procedures ensure organized storage with comprehensive transaction recording and pre-delivery examination.

Quality Certifications

Company History

2004: Recognized Brand of the Building Industry Material Market
2006: Certificate for Product Exemption from Quality Surveillance Inspection & ISO9001
2009: Advanced Company, Jiangsu Famous Brand Certificate, Credible Product of Quality in Jiangsu Province
2012: Established business relationships with Panasonic and LG
2015: Innovative producer and supplying partner for European clients
2017: Developed new baseboard heater products
2019: Cooperated with world's largest heater manufacturers as aluminum shell supplier
2023: Expanding overseas distributor network for win-win benefits

Notable Projects

Soccer City Stadium, Johannesburg

As the main aluminum supplier for Africa's largest stadium (94,000 seats), we contributed to this major South African construction project that received unanimous praise upon completion.

Lobster Trailers

Collaboration with this Nordic trailer giant involved our R&D team analyzing and improving designs, then processing with excellent equipment and technology to minimize costs and enhance product performance.

School Desk Project

Supplied aluminum legs for school desks through local customer Dadn, leveraging our strong design capabilities and mature technology to support successful project bidding.
