PVDF Electrophoresis Wooden Grain Custom Elevator Aluminium Profile with Sandblast and Anodizing

PVDF Electrophoresis Wooden Grain Custom Elevator Aluminium Profile with Sandblast and Anodizing
PVDF Electrophoresis Wooden Grain Custom Elevator Aluminium Profile with Sandblast and Anodizing PVDF Electrophoresis Wooden Grain Custom Elevator Aluminium Profile with Sandblast and Anodizing PVDF Electrophoresis Wooden Grain Custom Elevator Aluminium Profile with Sandblast and Anodizing PVDF Electrophoresis Wooden Grain Custom Elevator Aluminium Profile with Sandblast and Anodizing PVDF Electrophoresis Wooden Grain Custom Elevator Aluminium Profile with Sandblast and Anodizing PVDF Electrophoresis Wooden Grain Custom Elevator Aluminium Profile with Sandblast and Anodizing

Large Image :  PVDF Electrophoresis Wooden Grain Custom Elevator Aluminium Profile with Sandblast and Anodizing

Product Details:
Certification: SONCAP, ISO, RoHS, TUV
Document: Product Brochure PDF
Payment & Shipping Terms:
Minimum Order Quantity: 500
Price: 1
Contact Now
Detailed Product Description
Model NO.: Elevator Aluminum Profile Grade: 6000 Series
Temper: T3-T8 Alloy: 6063
Surface Finishing: Anodic Oxidation Size: 3m - 6m Per Piece
Thickness: 0.8 - 5.0mm Anodized Thickness: 8 - 25um
Powder Coated Thickness: 60- 120um Tensile Strength: ≥ 160Mpa (T5), ≥ 205Mpa (T6)
Yield Strength: ≥ 110Mpa (T5), ≥ 180Mpa (T6) Elongation: ≥ 8%
Production Capacity: 50000PCS /Month Extrusion Diameter: 400*150mm And φ360
MOQ: 500kgs
Highlight:

PVDF Electrophoresis Elevator Aluminium Profile

,

Wooden Grain Industrial Aluminium Profile

,

Sandblast and Anodizing Custom Aluminium Profile

Custom Aluminum Elevator Profiles
Our 4500T grade extrusion machine enables production of custom sections up to 400×150mm and φ360. We welcome your drawings and provide complete pricing breakdowns including aluminum ingot costs, extrusion, surfacing, and additional services. We also supply fully assembled premium grade window and door systems.
Product Specifications
Item Oxidation Construction Aluminum Profile / Aluminum Elevator Profile
Material Aluminium 6000 series alloy: 6063, 6005, 6061
Temper T4, T5, T6
Size 3m - 6m per piece, or customized
Shape Round, square, flat, hollow, oval, triangle, U-profile, L-profile, T-profile, custom available
Thickness 0.8 - 5.0mm
Application Elevator
Surface Treatment Options
Surface Treatment Mill-finish, anodized, powder coated, electrophoresis, brushed
Anodized Color Silver, black, champagne, bronze, gold or customized
Anodized Thickness 8 - 25μm
Electrophoresis Color Silver, black, champagne, bronze, gold or customized
Powder Coated Color Customized
Powder Coated Thickness 60 - 120μm
Guarantee Surface color stability for 10-20 years indoor use
Packaging Options
Bundles Packing Inside: EP foam protection for each piece
Outside: Waterproof craft paper wrapping
Carton Packing Inside: Individual plastic bag per piece
Outside: Multiple quantities in cartons
Wood Pallet Packing Inside: Bundles or cartons packing
Outside: Multiple bundles/cartons on wood pallets
Customized Requirement Customized packing requirements available
Service Details
MOQ 500kg per item; Typically 13-15 tons for 20GP; 25 tons for 40HQ
OEM Service Drawing, sample, or design service offered by customer
Production Capacity 5,000 metric tons monthly
Deep Processing CNC, drilling, milling, cutting, bending, tapping, welding, assembling, punching
Brand Name HENTEC
Certificates & Standards ISO9001-2008, ISO14001, SGS
Delivery Time Die development & sample testing: 12-18 days
Mass production: 20-30 days after sample confirmation
Payment Terms T/T, L/C
FOB Port Shanghai
Settlement Terms Final actual weight or drawing theoretical weight
Applications
Industrial aluminum profiles used in automotive, railway, machinery, electronics, medical, and other industrial fields. Aluminum frames serve as important auxiliary materials for hardware, machinery, electromechanical parts, and solar PV products. We also provide profiles for radiators, fitness equipment, construction, lighting instruments, ventilation ducts, and oil pipelines.
Technical Data
Chemical Composition
Alloy Si Fe Cu Mn Mg Cr Zn Ti Impurity Al
6063 0.2-0.6 0.35 0.1 0.1 0.45-0.9 0.1 0.1 0.1 0.15 Rest
6061 0.4-0.8 0.7 0.15-0.4 0.15 0.8-1.2 0.04-0.35 0.25 0.15 0.15 Rest
6060 0.3-0.6 0.1-0.3 0.1 0.1 0.35-0.6 - 0.15 0.1 0.15 Rest
6005 0.6-0.9 0.35 0.1 0.1 0.40-0.6 0.1 0.1 0.1 0.15 Rest
Mechanical Properties
Alloy Temper Tensile Strength Yield Strength Elongation
6063 T5 ≥ 160MPa ≥ 110MPa ≥ 8%
6063 T6 ≥ 205MPa ≥ 180MPa ≥ 8%
6061 T6 ≥ 265MPa ≥ 245MPa ≥ 8%
Technical Support
  • Custom design services including CAD drawings and 3D models for extruded profiles
  • Professional R&D team for design analysis and optimization to reduce costs and improve performance
  • Complete "one-stop" service from product design to surface treatment with quality control throughout production
PVDF Electrophoresis Wooden Grain Custom Elevator Aluminium Profile with Sandblast and Anodizing 0
Factory Equipment & Capabilities
Extrusion
44 aluminum extrusion lines with PLC control systems, capable of producing commercial and industrial profiles up to 350mm outer diameter. Our largest 6800-ton extruder handles complex profiles up to 600mm diameter for radiators, industrial fan blades, motor enclosures, solar cell frames, and architectural applications.
PVDF Electrophoresis Wooden Grain Custom Elevator Aluminium Profile with Sandblast and Anodizing 1
Anodizing
6 anodizing production lines creating uniform oxidation films for improved corrosion resistance, hardness, and wear resistance. Available in silver, black, gold, champagne, and imitation steel colors with strict quality control and re-processing of non-conforming products.
PVDF Electrophoresis Wooden Grain Custom Elevator Aluminium Profile with Sandblast and Anodizing 2 PVDF Electrophoresis Wooden Grain Custom Elevator Aluminium Profile with Sandblast and Anodizing 3
Painting
4 powder spraying lines using Gema Switzerland nozzles with environmentally friendly, durable paints featuring strong adhesion and color retention.
CNC Machining
Advanced machining equipment including 12 PRATIC machining centers for profiles up to 6 meters, automatic cutting machines from Wegoma, 30 punching machines (50-100 tons), bending machines, and milling machines for comprehensive processing capabilities.
PVDF Electrophoresis Wooden Grain Custom Elevator Aluminium Profile with Sandblast and Anodizing 4 PVDF Electrophoresis Wooden Grain Custom Elevator Aluminium Profile with Sandblast and Anodizing 5 PVDF Electrophoresis Wooden Grain Custom Elevator Aluminium Profile with Sandblast and Anodizing 6
Packing and Shipping
Manual packaging with strict warehouse management procedures, section-based storage, and thorough examination before delivery.
PVDF Electrophoresis Wooden Grain Custom Elevator Aluminium Profile with Sandblast and Anodizing 7
Certifications
PVDF Electrophoresis Wooden Grain Custom Elevator Aluminium Profile with Sandblast and Anodizing 8
Company History
  • 2004: Recognized brand of building industry material market
  • 2006: Product exemption certificate and ISO9001 certification
  • 2009: Advanced company, Jiangsu famous brand, credible product quality certificate
  • 2012: Established relationships with Panasonic and LG
  • 2015: Innovative producer and supplier for German clients
  • 2017: Developed new baseboard heater products
  • 2019: Supplier for world's largest heater manufacturers
  • 2023: Expanding overseas distributor network
Notable Projects
Soccer City Stadium, Johannesburg
Main aluminum supplier for Africa's largest capacity stadium (94,000 seats), contributing to this major South African project that received unanimous praise.
PVDF Electrophoresis Wooden Grain Custom Elevator Aluminium Profile with Sandblast and Anodizing 9
Lobster Trailers
Collaboration with Nordic trailer giant featuring design optimization and advanced processing to minimize costs and enhance product performance.
PVDF Electrophoresis Wooden Grain Custom Elevator Aluminium Profile with Sandblast and Anodizing 10
School Desk Project
Supplied aluminum legs for school desks, supporting local customer Dadn's successful bid with strong design capabilities and mature technology.
PVDF Electrophoresis Wooden Grain Custom Elevator Aluminium Profile with Sandblast and Anodizing 11
