6061 Aluminum Profile for Waterproof Electrical Box with Customized CNC Machining and Precision Machining

Large Image : 6061 Aluminum Profile for Waterproof Electrical Box with Customized CNC Machining and Precision Machining

Product Details:

Certification:	SONCAP, ISO, RoHS, TUV
Document:	Product Brochure PDF

Payment & Shipping Terms:

Minimum Order Quantity:	500
Price:	1

Contact Now

Detailed Product Description

Grade:	6000 Series	Temper:	T3-T8
Alloy:	6063	Surface Finishing:	Anodic Oxidation
Tensile Strength:	≥ 265Mpa	Yield Strength:	≥ 245Mpa
Elongation:	≥ 8%	Production Capacity:	50000PCS /Month
Max Diameter:	350mm	Extrusion Lines:	44
Anodizing Lines:	6	Powder Spraying Lines:	4
Machining Centers:	12	Punching Machines:	30
Bending Machines:	10
Highlight:	Waterproof Electrical Box Aluminum Profile , Customized CNC Machining Aluminum Extrusion Profile , Precision Machining 6061 Aluminum Profile

6061 Aluminum Profile for Waterproof Electrical Box with Customized CNC Machining

MetalPlus manufactures high-quality customized standardized enclosures, including aluminum profile housing, die-cast aluminum boxes, standard aluminum chassis, rack mount housing, and CNC precision machined parts.

Product Features

Material Options: Al6063, Al6061, Al6005, Al6060 in T4, T5, T6, T66 tempers
Design Features: Slots in extrusion for PCB and component mounting
Surface Treatments: Anodizing, bead blasting, silk screening, various plating options, painting, powder coating, and more
Performance: Excellent EMC shielding, corrosion resistance, heat dissipation
Machining Capabilities: Drilling, bending, precise cutting, and fabrication
Applications: Communication, medical, photoelectric, safety, and instrumentation

Product Components

S/N	Part Name	Quantity	Material
1	Extrusion profile	1	AL6063
2	Front and rear panels	2	AL
3	Screws	4/8	SS

Key Specifications

Aluminum top and bottom plate with case design
Ideal for rail transit, power equipment, marine monitoring, and harsh environments
Extruded aluminum frame with die-cast panels for waterproofing and heat dissipation
Horizontal PCB/chassis mounting via inner-grooved frame
Suitable for industrial control boxes, outdoor WiFi access points, and measurement instruments

Technical Data

Chemical Composition (%):

Alloy	Si	Fe	Cu	Mn	Mg	Cr	Zn	Ti	Impurity	Al
6063	0.2-0.6	0.35	0.1	0.1	0.45-0.9	0.1	0.1	0.1	0.15	Rest
6061	0.4-0.8	0.7	0.15-0.4	0.15	0.8-1.2	0.04-0.35	0.25	0.15	0.15	Rest

Mechanical Properties:

Alloy	Temper	Tensile Strength	Yield Strength	Elongation
6063	T5	≥ 160Mpa	≥ 110Mpa	≥ 8%
6061	T6	≥ 265Mpa	≥ 245Mpa	≥ 8%

Technical Support

Custom design services including CAD drawings and 3D models
R&D team for design optimization and cost reduction
Complete in-house production from design to surface treatment
Strict quality control throughout manufacturing process

Manufacturing Capabilities

Extrusion: 44 aluminum extrusion lines with maximum diameter of 350mm

Anodizing: 6 production lines with uniform oxidation film thickness

Painting: 4 powder spraying lines using Gema Switzerland equipment

CNC Machining: 12 PRATIC machining centers for complex profile processing

Quality Assurance

ISO9001:2015, ISO13485:2016 certified
SGS, RoHS, TU compliant
Strict quality control procedures
NDA (Non-disclosure Agreement) available

Applications

Inverters, signal amplifiers, video pushers, lithium-ion battery changers, mini hosts
