6063 Alloy LED Light Heatsink with 2 Year Warranty and ISO9001 Certified Aluminum Extrusion Profile

All Products
Aluminum Heatsink Extrusion Profiles (234)
Industrial Aluminium Profile (303)
Aluminum Extrusion Profile (69)
Aluminum Die Casting Parts (33)
Steel Casting Part (10)
Industrial Fan Blade (98)
Aluminium Profile System (115)
Aluminum Solar Panel Frame (79)
Aluminum Extrusions For Electronics (72)
Aluminum Window Extrusion Profiles (158)
Aluminum Curtain Wall Profile (31)
Construction Aluminum Profile (86)
Solar Roof Mounting Systems (95)
Anodized Aluminum Tube (30)
6061 Aluminum Profile (50)
Aluminum Hand Railings (15)
Aluminum Door Extrusions (45)
Extruded Aluminum Enclosure (44)
Window Door Accessories (17)
Aluminum Core Composite Panel (11)
Customized Project (5)
Injection Molding Products (1)
China Hentec Industry Co.,Ltd certification
China Hentec Industry Co.,Ltd certification
Thanks a lot for your support for more than 8 years ,we are really appreciate for the good quality of the products and the quality service .

—— James Scott

We have received the goods , they look perfect ,thanks for the help of Team Hentc .

—— Ane Unamuno

Le succès de ce nouveau projet dépend du support de l’équipe HENTEC en termes de technologie de traitement. Merci à HENTEC de nous aider à contrôler les coûts de manière efficace et à répondre à nos exigences en termes de haute qualité. Nous nous réjouissons de notre future collaboration!

—— Yann Pauwels

I'm Online Chat Now

6063 Alloy LED Light Heatsink with 2 Year Warranty and ISO9001 Certified Aluminum Extrusion Profile

6063 Alloy LED Light Heatsink with 2 Year Warranty and ISO9001 Certified Aluminum Extrusion Profile
6063 Alloy LED Light Heatsink with 2 Year Warranty and ISO9001 Certified Aluminum Extrusion Profile 6063 Alloy LED Light Heatsink with 2 Year Warranty and ISO9001 Certified Aluminum Extrusion Profile 6063 Alloy LED Light Heatsink with 2 Year Warranty and ISO9001 Certified Aluminum Extrusion Profile 6063 Alloy LED Light Heatsink with 2 Year Warranty and ISO9001 Certified Aluminum Extrusion Profile 6063 Alloy LED Light Heatsink with 2 Year Warranty and ISO9001 Certified Aluminum Extrusion Profile 6063 Alloy LED Light Heatsink with 2 Year Warranty and ISO9001 Certified Aluminum Extrusion Profile

Large Image :  6063 Alloy LED Light Heatsink with 2 Year Warranty and ISO9001 Certified Aluminum Extrusion Profile

Product Details:
Document: Product Brochure PDF
Payment & Shipping Terms:
Minimum Order Quantity: 500
Price: 1.99
Contact Now
Detailed Product Description
Material: Aluminum Color: Black
Shape: Round Surface Treatment: Mill Finish, Anodizeding, Sand Blasting, Powder Coating
Alloy Type: 6063, 6061, 6060, 6005 Tensile Strength: 160-265Mpa
Yield Strength: 110-245Mpa Elongation: ≥ 8%
Production Capacity: 50000PCS /Month Max Diameter: 350mm
Max Extrusion Diameter: 600mm CNC Machining Length: Up To 6 Meters
Punching Thickness: Over 5MM Anodizing Colors: Silver, Black, Gold, Champagne, Imitation Steel
Delivery Time: 7~10 Days
Highlight:

6063 Alloy LED Light Heatsink

,

2 Year Warranty Aluminum Extrusion Profile

,

ISO9001 Certified Aluminum Heat Sink

Silvery Anodized Custom LED Light Heatsink Extrusion Profiles with CNC Machining
Aluminum heat sink extrusion is the most common and cost-efficient thermal solution for electronic devices and industrial applications. Our extruded aluminum heat sinks offer lightweight construction, excellent thermal performance, and cost-effective manufacturing.
Product Specifications
Product Name Aluminum Alloy LED Heat Sink
Raw Material Aluminium
Surface Treatment Mill finish, Anodizing, Sand Blasting, Powder coating
Equipment CNC machine, grinding and shot peening machine, Precise tensile strength testers, magnetic powder flaw detectors
Deep Processing Cutting, Drilling, Tapping, Polish, Milling
Certification ISO9001, SGS certificate, ROHS report
Usage High-power Semiconductor, Power Electronics cooling, LED/lamp electronic ballast, audio equipment, power amplifier circuits, automatic control meters
Delivery Time 7-10 Days after order confirmation
Technology Support
With over 600 employees including 50 R&D specialists, we provide comprehensive support from initial design to final production. Our process includes:
  • Rapid design drawing and specification development
  • Quick quotation and lead time confirmation
  • Prototype production and testing
  • Full-scale production after approval
Applications
Our heat sinks are essential components in various industries, including:
  • Audio Equipment
  • UPS/EPS power supplies
  • Inverters and transformers
  • Battery packs and new energy controllers
  • Charging piles and welding machines
  • Communication transmitters and base stations
  • Control cabinets and power regulators
Company Advantages
  • ISO 9001:2008 certified
  • Comprehensive production facilities including extrusion machines, powder painting lines, and CNC equipment
  • Advanced equipment and excellent R&D team
  • Professional designers and experienced workers
  • Strict quality control with 100% inspection
  • Highly skilled manufacturing processes
Technical Data
Chemical Composition
Alloy Si Fe Cu Mn Mg Cr Zn Ti Impurity Al
6063 0.2-0.6 0.35 0.1 0.1 0.45-0.9 0.1 0.1 0.1 0.15 Rest
6061 0.4-0.8 0.7 0.15-0.4 0.15 0.8-1.2 0.04-0.35 0.25 0.15 0.15 Rest
6060 0.3-0.6 0.1-0.3 0.1 0.1 0.35-0.6 - 0.15 0.1 0.15 Rest
6005 0.6-0.9 0.35 0.1 0.1 0.40-0.6 0.1 0.1 0.1 0.15 Rest
Mechanical Properties
Alloy Temper Tensile Strength Yield Strength Elongation
6063 T5 ≥ 160Mpa ≥ 110Mpa ≥ 8%
6063 T6 ≥ 205Mpa ≥ 180Mpa ≥ 8%
6061 T6 ≥ 265Mpa ≥ 245Mpa ≥ 8%
Production Capabilities
Our comprehensive services include:
  • Custom profile design with CAD drawings and 3D models
  • Design optimization to reduce costs and improve performance
  • Complete "one-stop" production from design to surface treatment
6063 Alloy LED Light Heatsink with 2 Year Warranty and ISO9001 Certified Aluminum Extrusion Profile 0
Factory Equipment
Our manufacturing capabilities include:
  • 44 aluminum extrusion lines with maximum outer diameter of 350mm
  • 6800 ton extruder for industrial profiles up to 600mm diameter
  • 6 anodizing production lines with uniform oxidation film thickness
  • 4 powder spraying lines with high-quality Swiss equipment
  • Advanced CNC machining centers for complex profiles
6063 Alloy LED Light Heatsink with 2 Year Warranty and ISO9001 Certified Aluminum Extrusion Profile 1 6063 Alloy LED Light Heatsink with 2 Year Warranty and ISO9001 Certified Aluminum Extrusion Profile 2 6063 Alloy LED Light Heatsink with 2 Year Warranty and ISO9001 Certified Aluminum Extrusion Profile 3
Quality Assurance
We maintain strict quality control throughout our production process:
  • Professional inspectors examine all anodized products
  • Defective products are either reprocessed or scrapped
  • Color consistency is maintained across production batches
  • 100% inspection before packing
6063 Alloy LED Light Heatsink with 2 Year Warranty and ISO9001 Certified Aluminum Extrusion Profile 4 6063 Alloy LED Light Heatsink with 2 Year Warranty and ISO9001 Certified Aluminum Extrusion Profile 5 6063 Alloy LED Light Heatsink with 2 Year Warranty and ISO9001 Certified Aluminum Extrusion Profile 6
Packaging and Shipping
All products are carefully packaged and undergo strict warehouse management procedures to ensure quality upon delivery.
6063 Alloy LED Light Heatsink with 2 Year Warranty and ISO9001 Certified Aluminum Extrusion Profile 7
Certifications
6063 Alloy LED Light Heatsink with 2 Year Warranty and ISO9001 Certified Aluminum Extrusion Profile 8
Notable Projects
We're proud to have supplied aluminum components for major projects including:
  • Soccer City Stadium in Johannesburg - the largest capacity stadium in Africa
  • Collaboration with Lobster Trailers, a Nordic trailer manufacturer
6063 Alloy LED Light Heatsink with 2 Year Warranty and ISO9001 Certified Aluminum Extrusion Profile 9 6063 Alloy LED Light Heatsink with 2 Year Warranty and ISO9001 Certified Aluminum Extrusion Profile 10
